Jiangsu Jumbo Building Material & Technologies Co.,Ltd

Jiangsu Jumbo Building Material & Technologies Co.,Ltd We are the biggest manufacturer of lightweight wall panels in China. Our products are used as non-bearing load interior and partition walls for

Active Member

11 Years

Home > Prefabricated Partition Walls >

Lightweight Prefabricated Partition Wall Panel

    Buy cheap Lightweight Prefabricated Partition Wall Panel from wholesalers

    Buy cheap Lightweight Prefabricated Partition Wall Panel from wholesalers
    • Buy cheap Lightweight Prefabricated Partition Wall Panel from wholesalers

    Lightweight Prefabricated Partition Wall Panel

    Ask Lasest Price
    Brand Name : Jumbo,OEM service
    Model Number : JB100
    Certification : ISO9001,ISO14001,TUV
    Price : FOB Shanghai,CIF,EXW
    Payment Terms : T/T
    Supply Ability : Over 2 million square meters per year
    Delivery Time : 12 days after the deposit
    • Product Details
    • Company Profile

    Lightweight Prefabricated Partition Wall Panel

    High Strength Waterproof Prefabricated Lightweight Partition Wall Panel For Office


    Quick Details:


    Size (mm): 2700*600*100

    Usages: Interior wall (Non-bearing wall)

    Structure: Hollow core

    Density(Kg/m²): 42±1.5

    Strength(MPa): 4.0

    Raw Material: MgO,fly ash,fibers


    Description:


    JB lightweight wall panels are widely used as interior wall on various buildings, such as shopping malls, residential building, office buildings, hotels and etc.

    Features:


    1. Lightweight:Only 42kg/m²,low ocean freight and engineering cost


    2. Easy&fast installation: 2 workers for nearly 100m²/day, no special installation technic required.


    3. No plaster work after installation, only need 2 or 3mm skim coat, then paint directly, 100% mortar will be saved


    4. Over 3 hours fire resistance can ensure the whole building's security


    5. Hollow core structure is specially designed for electrical conduits and pipes, which will bring a lot of conveniences at site


    6. the maximum hanging can reach up to 4000N, which is great for hanging TV sets, air conditions, washing basin and etc


    7. Ring beam will be only required when the wall height is over 5 meters, column will be only required when the wall width is over 6 meters


    8. All raw materials are totally inorganic and environment friendly


    Specification:


    Size(mm)2700*600*100(L*W*T) can be customized
    Density(kg/m²)42±1.5
    Strength(MPa)4.0
    Drying contraction(mm/m)0.25
    Softening Coefficient0.8
    Bending Failure Load2.2
    Hanging forice (N)>1000
    Moisture(%)7.9
    Fire resistance (h)3
    Sound Insulation(dB)39

    Installed walls at site:



    Connection Details:
